Combustion Vertical Chamber Apparatus Standard IEC60332-1-1 Fire Propagation Test

Product Categories
Suzhou Yangyi Vouch Testing technology Co.,Ltd
Contact Now

Combustion Vertical Chamber Apparatus Standard IEC60332-1-1 Fire Propagation Test

Brand Name : VOUCH

Model Number : 5704

Certification : ISO

Place of Origin : CHINA

MOQ : 1 SET

Price : NEGOTIABLE

Payment Terms : TT

Supply Ability : 30SETS PER MONTH

Delivery Time : 30DAYS

Packaging Details : WOODEN CASE

POWER : 220V

WARRANTY : 1YEAR

PACKAGE : STANDARD EXPORT PACKAGE

STANDARD : IEC60332

MODEL : 5704

DELIVERY : 30DAYS

Contact Now

Single wire cable vertical combustion test

Feature:

  1. import time and temperature controller,digital display and box separat designed
  2. 2mm stainless steel molding by numerically control ,beautiful,durable
  3. Special used burner and clamp ,complete in accord with standard requirement
  4. Pneumatic type motor control,no need man operate

Technical data:

  1. Model:5704
  2. Execute standard:GB18380.11
  3. Test area size(mm) :320w*470d*1200h
  4. Flame height adjust:10-250mm
  5. Propane flow adjust: 100-1000l mm/min
  6. Air flow: 1-10l/min
  7. Flame temperature test: max1050degree
  8. Temperature rise timing:0-99h 59m 59.9s
  9. Flame angle adjust:0-45degree
  10. Application combustion time adjust range:0-99.99s
  11. Application combustion resolution:0.01s
  12. Temperature rise resolution:0.1s

Choose configure: 18380.21 burnr and test fuction

Model 5704
Test area size 320w*470d*1200h
Temperature rise timing

0-99h 59m 59.9s
Flame height adjust

10-250mm
Air flow

1-10l/min

Combustion Vertical Chamber Apparatus Standard IEC60332-1-1 Fire Propagation TestCombustion Vertical Chamber Apparatus Standard IEC60332-1-1 Fire Propagation TestCombustion Vertical Chamber Apparatus Standard IEC60332-1-1 Fire Propagation Test
